Датчик головы Renishaw MIH (A-1070-0003)
576 643 ₽
*Спец цены для госкомпаний
A manually indexable head, repeatable in 720 positions over two axes with LCD display, the MIH is designed for use with the autojoint TP6A touch probe and long extensions for large components. TP2, TP6, TP20 touch probes can be used with the addition
Описание
Renishaw MIH Probe Head
A manually indexable head, repeatable in 720 positions over two axes with LCD display, the MIH is designed for use with the autojoint TP6A touch probe and long extensions for large components. TP2, TP6, TP20 touch probes can be used with the addition of the PAA1 or PAA2 extensions.
| 2σ positional repeatability | 1 Μm |
| Probe status indication | 1 LED |
| Cable connection | 5 pin DIN 180° socket |
| A-axis indexing | 105° to 0° in 15° in 7.5° steps = 15 positions |
| B-axis indexing | ±180° in 7.5° steps = 28 positions |
| Probe mounting | Autojoint |
| Mounting options | Shank to suit your CMM |
Part Number: A-1070-0003
